Model: Gold Plus 3 + 3 System
Key Features:
| Gauge | 5G,7G,3-5-7G,8G,9G,10G,12G,8-10-12G,14G,16G, |
| Knitting Width | 80", 100" |
| Knitting Speed | Controlled by servo motor with 32 sections speed optional max 1.4 m/s |
| Knitting System | Double carriage triple system with high position roller |
| Knitting Function | Knit, miss, tuck, transfer, pointelle, intarsia, jacquard, hide or apparent shaping and other regular and irregular patterns |
| Racking Patterns | Controlled by AC servo motor racking within 2 inches and with fine micro adjustable function |
| Encoder | Advanced Encoder adopted |
| Tranfer Cam | Combined type transfer cam, both single and double system all can transfer seprately or synchronously, also can transfer by one system, knitting by another, which will achieve high efficiency |
| Dynamic Stitch | The skill is initiation in China and at the same level with similar machines internaonally. Different tightness is allowed on the same line without problem of varying lengths while knitting. When group of rib, twisted flower and front-back are knitted on the same line they are allowed to loose alone |
| Technology of stitch motor closed-loop | Intelligently controlling the working condition of stitch motor is phased with this technology,avoiding the problem of wrong tightness while knitting |
| Sinker System | Controlled by stepping motor, adjustable to different knitwear ,achieve various results of narrowing and widening |
| Rapid Gyration | With rapid gyration in one-needle period,the efficiency can be raised by 14% especially when knitting narrow weaving like sleeve |
| Intelligent Traction Control | Provide different kinds of tracon;slove the problem that tracon may be lacking on thick-needle machine; release traction to make stitch transfer more stable |
| Take Down Roller | Computerized, controlled by stepping motor,32 levels selection of tension with ajustable scope 0-100, Additional Take Down (Optional) |
| Yarn Carrier | 2x16 yarn feeders on both sides of 1 guide rail of 8, switchover on any position of needle bed (special intarsia yarn feeders optional) |
| Protection | The machine will automacally alarm if yarn-breaking, knots floang, rewind, end of knitting, fail of racking, needle jack crash, error programming occur, also with safety auto lock protection device |
| Function of Intelligent Computer Files | Create parameters like thickness,traction and speed with intelligent plate making program, save time for creating parameters on the machine |
| PC System | 1. LCD touch screen, graphical interface. USB and network compatible, with expanded memory of up to 1G. A great amount of patterns can be stored and mobilized for use at any time as per production requirements. |
| 2. Monitoring display: Various operating parameters can be displayed and can be adjusted anytime when the machine is running, making operations as convenient and time-saving as possible. | |
| 3.Design system and control system (sofwares) are easy to update for free. | |
| Power | Single-phase 220V, adopt advanced CMOS technology enabling memorizing at the instant of power outage and restoring of knitting thereafter |
Ramana Machines, Ludhiana, India
